SD05 Integrated Signal Indicator

Model : SD05
Input signal : 4 ... 20 mA(2-Wire) / 0 ... 10V(3-Wire)
Electrical connection: DIN 43650: 330° / M12: 210°
Accuracy: 0.2%F.S.
Display: On-site display / 4 ... 20 mA / 0 ... 10V
  • Features
    ● SD05: 330° turnable, the direction of panel is changeable, good monitoring angle without blind corner
    ● Display : On-site display / 4 ... 20 mA / 0 ... 10V
    ● Programmable, display value can be set according to sensor's spec
    ● Integrated display connected with 2-wire or 3-wire transmitter suitable for the on-site application
    ● The power is from 2-wire signal loop, 3-wire no extra power supply is required, easy to install
    ● Programmable by pressing 2 buttons, easy to operate
    ● High performance, good stability and functionality
    ● Input signal: 4 ... 20 mA(2-Wire) / 0 ... 10V(3-Wire)

    eYc SD05 Display value setting


  • Applications
    With extensive applications as process monitoring in semiconductor industry / Steel industry / Chemical industry / Environmental engineering / Food processing / Pharmaceutical industry /
    Water plants / Power plants / Research and development
  • Download
  • Specification
    Input
    Input signal:4 ... 20 mA(2-wire) / 0 ... 10 V(3-wire), Eg : Pressure / Differential pressure / Temp. / Flow / PH value / Load cell, etc
    Parameter setting:Programmable by pressing the button

    Output
    Display method:4-Digit LED (Height of word : 9.2 mm)
    Display range:-1999 ... +9999
    Scale:Decimal point, programmable
    Accuracy:0.2%F.S.
    Overload current:40 mA (2-wire)

    Electrical
    Power supply:DC 4 ... 20 mA,2-wire / DC 12 ... 33 V,3-wire
    Electrical connector:DIN 43650 : 330° / M12 : 210°

    Environment
    Operating Temp.:20°C ... 60°C
    Operating Humid.:0 ... 95%RH (Non-condensing)

    Protection
    IP Rating:IP 65
    Electric protection:■ Polarity protection

    Certification
    Certification:CE

    Material
    Housing (Body):ABS(UL94V-0) + PC(UL94V-2)
    Weight:H : 125 g / M : 127 g


    Option list
    M12-F4N-200
    M12 Waterproof

Note : Design and specifications are subject to change without notice.
Note : If the product has RS-485 function, to avoid damaging product, please make sure the product and the device which connect with RS-485 are on common ground.
